Audio Authority AVP-11D UniDrive
1:1 Active Dual Cat 5 Component / Digital Audio Extender System with Decora Wallplate Receiver
Audio Authority AVP-11D UniDrive 1:1 Active Dual Cat 5 Component / Digital Audio Extender System with Decora Wallplate Receiver
This Audio Authority AVP-11D UniDrive 1:1 Active Dual Cat 5 Component / Digital Audio Extender System uses an active design, so it can transmit high-definition component video, as well as both analog and digital audio, up to 1000 feet, using inexpensive CAT5-type cables - a range that passive balun systems simply cannot achieve! If you need Cat5-type cables, we have them available here.
Employing Audio Authority's industry-leading AGE (Active Gain Equalization) technology, the UniDrive system delivers
pristine HDTV video at all resolutions up to 1080p, as well as full bandwidth analog stereo audio and multi-channel
digital audio. The
AVP-11D even includes a return pathway for IR control. The enclosed transmitter unit can be mounted just
about anywhere and the receiver can be easily installed in a standard deep single-gang electrical box.
If you would prefer to have an enclosed receiver unit (similar to the transmitter), please check out this system or click here to see a comparison of all Audio Authority Component Video over Cat-5 Distribution Systems.
Like most Audio Authority products, the AVP-11D comes with a one year limited warranty from the manufacturer.
Audio Authority's Description
UniDrive™ 1:1 Active Dual Cat 5 Extender System
Model AVP-11
- Extends one source to one destination over two Cat 5e/6 cables
- Component video, analog audio, and digital audio
- Active balanced line technology rejects outside interference
- Maximum extension distance of 1,000 feet
- AGE (Active Gain Equalization) technology for maximum picture quality
- Made in the USA
Overview
The UniDrive is "A Better Kind of Balun" - a high performance active point-to-point Cat 5 extender capable of distributing high definition component video, analog stereo audio, and digital audio signals from one source to one display over distances up to 1,000 feet. Including proprietary A.G.E. (Active Gain Equalization) technology, high frequency signals are presented with their original quality intact. Incorporating the key signal paths necessary for premium audio and video entertainment, plus an IR pathway for easy remote control of AV components, the AVP-11D replaces six coaxial cables with two inexpensive, easy to install Cat 5 cables, and requires no power at the Cat 5 Receiver.
- Up to 1080p component video (YPbPr)
- Coaxial digital and stereo analog audio
- Infrared remote jack for IR pathway
- Only one power supply required: Receiver is phantom-powered through Cat 5 cable
- Single-gang Wallplate includes three Decora color inserts
- Alternative Cat 5 Wallplate/receivers: Model 9878 and 9879
Features
Key Features
- Distributes video and audio over two Cat 5e/6 cables
- Transmits one source to one destination
- AGE (Active Gain Equalization) technology for maximum picture quality
- Balanced line technology rejects outside interference
- Extends component video, analog audio, and digital audio up to 1,000 feet
Inputs/Outputs
- Component video (YPbPr) - 1/1
- Digital audio (coaxial and optical) - 1/1
- Analog stereo audio (L/R) - 1/1
- IR pathway - 1/1
What makes the UniDrive "A Better Kind of Balun"?
- Proprietary A.G.E.(Active Gain Equalization) circuitry allows for compensation over long distances, something a passive balun can't deliver
- More installation friendly than most "active" baluns - power pack is only required at the transmitter, making for a clean appearance in the viewing area
- Wide variety of signal types meet almost any installation requirement (component video, analog audio, digital audio, and IR)
Receiver Options
[The included 9879 Cat 5 receiver is easy to install in a standard deep, single-gang electrical box. 9879 wallplate/receivers come with three Decora color inserts: white, ivory, and almond.
The UniDrive transmitter is also compatible with the 9878 and 9890 receivers. 9878 wallplate/receivers that can be installed in standard shallow dual-gang electrical boxes. 9880 enclosed receivers can be conveniently mounted on any surface, on or inside a wall, or even on a TV or TV mount.
See AVP-11 for a kit that includes a 9880 enclosed receiver.]
The Infrared Pathway
The 3.5mm IR jacks provide convenient access for a third party IR remote distribution network over the passive, three-wire pathway on the Cat 5 cable. IR receiver and emitter equipment is not included.
Specifications
Video Parameters
- Video Formats: 480i/p, 576i/p, 720p, 1080i/p
- Input/Output Impedance: 75 ohms
- Input Ground Isolation: Yes
- Gain: 1
- Gain Accuracy: 2%
- 3dB Bandwidth: 120MHz
- Input Coupling: AC
- S/N Ratio: 65dB
- Max Equalization: 40dB equalization
Audio Parameters
- Input Impedance: 75 ohms/100K ohms
- Min Load Impedance: 75 ohms/10K ohms
- Multi-channel Digital: Yes
- Frequency Response: 10-50KHz
- S/N Ratio: 55dB
- THD+Noise: 0.10%
- Crosstalk: -70dB
Miscellaneous
- Connector Types (Tx Input, Rx Output): RCA (YPbPr, analog audio, digital coaxial audio), Toslink (digital optical)
- Connector Types (Tx Output, Rx Input): Dual RJ-45 (6 Cat 5 matrix outputs), RCA (local output)
- Dimensions (HxWxD, inches): 9880T Transmitter: 1.75 x 3.75 x 3; 9880 Receiver : 1.75 x 3.75 x 3
- Shipping Weight: 1.65 lbs.
- Agency Approvals: FCC, CE
- DC Input Connector: 5.5 x 2.1mm
- DC Input Voltage/Polarity: 18V/Center Positive
- Max DC Input Current: 250mA
- Heat Output: N/A
In the Box
- Power Supply: Model 571-014
- Mounting screws (8)
- User Manual
Downloads
Documents
Here is a closer look at the included 1180T enclosed transmitter.
This is the included 9880T enclosed transmitter.
This picture illustrates the connections on the transmitter back panel.
Shown here is the included 9879 Decora wallplate receiver.
In this photo the CAT-5 connections can be seen.
This is the left side of the receiver unit.
Shown here are the items that are included with the AVP-11D UniDrive system.
Here is the AVP-11 UniDrive product focus sheet. Click to download PDF.
Here is the User Manual - click to download in PDF format.
