Intelix INT-HD70-RX HDBaseT HDMI Receiver
HDMI, IR, RS232, and Ethernet over Single Twisted Pair
Intelix INT-HD70-RX HDMI, bi-directional IR, RS232 and Ethernet via HDBaseT Receiver
The Intelix INT-HD70-RX HDBaseT HDMI Receiver handles HDMI, bi-directional IR, bi-directional RS232 and Ethernet over a single twisted-pair cable, such as cat-5e or Cat-6.
Leveraging HDBaseT technology for enhanced transmission over shielded and unshielded twisted pair cabling, the INT-HD70-RX features power over HDBaseT (PoH), allowing flexible power on either the transmitter or receiver. Plus, other compatible PoH devices will power or be powered by the INT-HD70-RX.
The INT-HD70-RX supports 1080p, and 3D video up to 70 meters (230 feet). 4K x 2K up to 40 meters (131 feet). Built-in surge protection and diagnostic LEDs ensure hassle-free and robust installations. The system is HDMI v1.4 and HDCP 1.4/2.2 compliant, so it handles advanced HDMI video formats, including (but not limited to) 1080p, 4K, 2D, 3D, 120Hz, 240Hz, along with up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio lossless audio formats.
Ideal for use with Intelix INT-HD70-RX HDBaseT receivers (add to cart below), as well as compatible HDBaseT distribution systems and transmitter (see the list in the specs below).
Wired remote IR emitters and receivers are available as an option, as are a 12-slot rack-mounting kit and a rack-mount power supply for up to 12 devices (add to cart below).
As with virtually all systems that are based upon twisted-pair cable technology, the Intelix INT-HD70-RX HDBaseT HDMI Receiver will work with virtually any twisted-pair cables, including Cat-5e and Cat-6, but range and bandwidth is directly related to both distance and cable quality, so to get the highest resolutions at the greatest distances, you will want high-quality, low-skew cables. If you want the very best pre-terminated cables, please consider our VideoTwist cables.
Like most Intelix products, the INT-HD70-RX comes with a two year limited warranty from the manufacturer.
Intelix's Description
INT-HD70-RX
HDMI Slim 70M, POH, IR and Control HDBaseT Extender - Transmitter
The Intelix INT-HD70-RX extends HDMI, IR, and RS232 over a single solid core shielded Category 5e or greater cable using the Valens VS010TX HDBaseT chip. The INT-HD70-RX supports a 1080p video signal, including HDCP 2.2 and multichannel audio, up to 70m, as well as 3D and 4K x 2K (UHD) signals up to 40m. Built-in surge protection and diagnostic LEDs ensure hassle-free and robust installations. Flexible power design allows the units to be powered at either the TX or RX end, and only one power supply is required. The power supply is included; IR accessories (DIGIB-EMT and DIGIB-EYE) are sold separately.
The INT-HD70 series extenders are compatible with all Intelix HDBaseT product offerings and any product that meets the HDBaseT specifications.
Specifications
| Product Line: | INT-HD70-RX |
|---|---|
| Input/Output Connections | |
| HDMI Input | One (1) HDMI Type A Receptacle |
| HDBaseT Port | One (1) 8P8C port (Shielded RJ45) |
| Power | One (1) 5.5 mm OD, 2.6 mm ID Threaded Barrel |
| RS232 Port | One (1) 3-pin Removable Terminal Block Connector |
| IR Input | One (1) 3.5 mm TRS Receptacle |
| IR Output | One (1) 3.5 mm TRS Receptacle |
| Supported Audio, Video and Control | |
| Video Resolutions | SMPTE: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, UHD/30 |
| VESA: Resolutions up to 1920x1200 | |
| Color Depth: 24, 30, 36, 48bit | |
| Maximum Video Compatibility at 70 m | Deep Color 36/30/24 Bit at 1080p |
| Maximum Video Compatibility at 40 m | 1080p 3D, UHD/30, Deep Color 48 Bit at 1080p |
| Video Compliance | HDMI 1.4 and HDCP 1.4/2.2 |
| Embedded Audio | Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio |
| ARC (Audio Return Channel) | No |
| HEC (HDMI Ethernet Channel) | No |
| CEC (Consumer Electronics Control) | Yes (Pass-through Only) |
| Supported Baud Rates | 2400, 4800, 9600, 19200, 38400, 57600, 115200 |
| Supported IR Carrier Frequencies | 33 to 55 kHz |
| HDBaseT Signal Characteristics | |
| Maximum Distance | 70 m (229 ft.) |
| Cable Requirements | Continuous shielded solid core Cat 5e or greater with TIA/EIA-568B crimp pattern (no couplers in-line) |
| Bandwidth | 10.2 Gbps |
| HDBaseT Chipset | VS010TX |
| Chassis and Environmental | |
| Construction | Black Aluminum |
| Dimensions (H x W x D) | 16.2 mm x 115 mm x 84 mm (0.64 in x 4.73 in x 3.31 in) |
| Operating Temperature | 0° to +40° C (+32° to +104° F) |
| Operating Humidity | 20% to 90%, Non-condensing |
| Storage Temperature | -10° to +60° C (+14° to +140° F) |
| Storage Humidity | 20% to 90%, Non-condensing |
| Power and Regulatory | |
| Power Input | 24V DC 1.25A or 48V DC PoH (Power over HDBaseT) |
| Power Output | 48V DC PoH (Power over HDBaseT) |
| Power over Ethernet (PoE) Compatibility | 802.3af Alternative A |
| Power Consumption | 5 watts |
| ESD Protection | 15kV air, 8kV contact |
| Regulatory | FCC, CE, RoHS |
| Other | |
| Warranty | 2 years |
| Diagnostic Indicators | HDCP, Link, and Power |
| Included Accessories | Installation Guide, Power Supply, 3-pin Removable Screw Terminal |
| Optional Accessories | IR emitter (DIGIB-EMT), IR receiver (DIGIB-EYE), rack mount (INT-EXRMK), rack mounted power supply (PSU12) |
| HDBaseT Receiver (A/V, PoE, Control) Compatibility | DIGI-HD60C-R, DIGI-HDX-R, FLX-64, INT-HD70-RX, INT-HDX100-RX, DIGI-BSR-4K |
| HDBaseT Receiver (A/V, Control) Compatibility | FLX-BI4 |
| HDBaseT Receiver (A/V and PoE) Compatibility | DIGI-HD60-R |
| Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical interference, and cable patches. | |
Documentation and Downloads
Intelix INT-HD70-RX HDMI extender Receiver, back
