Intelix DIGI-HD-IR3-WP-R HDMI and IR over Twisted-Pair Wallplate Extender Receiver
Pro-grade Cat5 / Cat6 UTP Extender
Intelix DIGI-HD-IR3-WP-R HDMI and IR over Twisted-Pair Wallplate Extender Receiver
The Intelix DIGI-HD-IR3-WP-R HDMI and bi-directional IR over Twisted-Pair Wallplate Extender
Receiver
Ideal for residential A/V, commercial A/V, and digital signage applications, the
DIGI-HD-IR3-WP-R receives 1080p video at distances up to up to 150 feet, and 1080i, 720p 480p and 480i video at
distances as great as 300 feet.
Built-in buffering and amplification allow multiple units to be linked for greater distances, and ESD protection safeguards connected equipment from power strikes and surges.
Intelix's built-in HDshāk® technology provides dynamic EDID/DDC guaranteeing performance and image quality. This trademarked HDshāk® processing allows the DIGI-HD-IR3-WP to deliver the highest level of EDID and DDC negotiation, ensuring proper source and destination HDCP handshaking even over extended distances of twisted pair cabling. Features include dynamic EDID transfer, built-in EDID tables, customizable EDID storing, and bandwidth limiting.
Included in the box is a receiver, IR-Eye, IR-Emitter and a power supply. The unit may be powered from the front via a DIN connector or on the rear with a screw down connector.
These units are sold singly, so you must combine with a compatible twisted-pair transmitter or distribution system (sold separately), so you can get exactly the functionality you need. Use any one of the following transmitters/distribution systems:
- DIGI-HD-IR3-WP-S Wallplate Transmitter
- DIGI-HD-IR3-S Enclosed Transmitter
- DIGI-HD-XR Enclosed Receiver / Repeater - use to extend range and/or to add cascaded HDMI outputs.
- DIGI-HD-1X4 Distribution System
- DIGI-HD-4X8 Distribution System
- DIGI-HD-4X2 Distribution System
- DIGI-HD-4X4 Distribution System
- DIGI-HD-4X8 Distribution System
- DIGI-HD-8X8 Distribution System
As with virtually all systems that are based upon twisted-pair cable technology, the Intelix DIGI-HD-IR3-WP-R will work with virtually any twisted-pair cables, including Cat-5e and Cat-6, but range and bandwidth is directly related to both distance and cable quality, so to get the highest resolutions at the greatest distances, you will want high-quality, low-skew cables. If you want the very best pre-terminated cables, please consider our VideoTwist cables.
Like most Intelix products, the DIGI-HD-IR3-WP-R comes with a two year limited warranty from the manufacturer.
Intelix's Description
Rec Balun, HDMI w/IR, UTP
Application:
- Extending HDMI/IR over two twisted pair cables
Features
- Double-Gang Extender Wallplate
- Supports 1080p video up to 150ft over a dual Cat6 STP
- 33-55KHz IR Frequency Range
- Supports multi-channel digital audio
- May be powered from front or rear
Specifications
Download Spec Sheet
In this drawing the back of the receiver unit can be seen in greater detail.
This is the spec sheet, in PDF format.
Here is the Installation Manual, in PDF format.
