The Vutec Lectric I series feature outstanding quality in a popularly-priced screen. Vutec's exclusive E-Z Mounting System features an advanced heavy-duty extruded aluminum housing with channels in both the back and the top for easy wall or ceiling mounting. Standard housing colors are white, black, or gray.
These screens feature a motor-in-roller assembly design for silent, dependable operation. A three position wall switch is included, and the screen can also interface with low voltage relays, IR, and RF remote controls (available separately).
Surface choices include Matte White and Vu-Flex Pro, as well as SoundScreen and GreyDove SoundScreen acoustically transparent fabrics. Standard drop (leader) is 12".
Please contact us for pricing on custom options, including additional and/or perforated leader, custom screen sizes, and custom case colors.
The standard sizes are shown below.
| 16:9 (1.78:1) HDTV Format |
|
|
| Diagonal Size (inches) |
Viewing Area (inches) |
Shipping Weight (pounds) |
| 92 |
45 x 80 |
38 |
| 103 |
50.5 x 89.75 |
40 |
| 110 |
54 x 96 |
43 |
| 123 |
60 x 107 |
50 |
| 133 |
65 x 116 |
60 |
| 147 |
72 x 128 |
72 |
| (1.85:1) Professional Format |
|
|
| Diagonal Size (inches) |
Viewing Area (inches) |
Shipping Weight (pounds) |
| 91 |
43.25 x 80 |
50 |
| 113.5 |
54 x 100 |
60 |
| 126.5 |
60 x 111 |
72 |
| 151.5 |
72 x 133.25 |
80 |
| 4:3 (1.33:1) Video Format |
|
|
| Diagonal Size (inches) |
Viewing Area (inches) |
Shipping Weight (pounds) |
| 72 |
43.25 x 57.5 |
38 |
| 78 |
46.75 x 62.25 |
40 |
| 84 |
50.50 x 67.25 |
43 |
| 100 |
60 x 80 |
50 |
| 120 |
72 x 96 |
60 |
| 144 |
86.25 x 115.25 |
72 |
| 150 |
90 x 120 |
76 |
| 160 |
96 x 128 |
80 |
| 180 |
108 x 144 |
88 |
| 200 |
119 x 159 |
100 |
| 1:1 A/V Format |
|
|
| Viewing Area (inches) |
|
Shipping Weight (pounds) |
| 50 x 50 |
|
38 |
| 60 x 60 |
|
40 |
| 70 x 70 |
|
45 |
| 84 x 84 |
|
50 |
| 96 x 96 |
|
60 |
Why Cable Solutions?
Customer service is our first priority. We do our best to help you find
the best solutions for your particular application. We're enthusiasts too,
so we know what it's like to wait for cables and accessories that are needed to
get your new system up and running. We also know how important it is to be able to get a
response when you need help, so you'll often find us working long hours in an
effort to get you the answers that you need.
Design excellence, high quality materials, meticulous workmanship, and
superior service...put it all together and you get a superior product.
Don't get stuck with bad advice, poor service, slow shipment or an inferior
product. If you want the best, here it is.
Miscellaneous
Please click here |
Click on any of the pictures below for a closer
view!!
Vutec Lectric I
This drawing shows dimensional details for 1.78:1, 1.85:1 and 1.33:1 screens.
A/V format screens come with 1" side borders and black leader. Housing size is viewing area width plus 7 1/2"
Cross-section drawing of the housing
|
